280X45D SDR11 ELBOW LONG SPIGOT POLYETHYLENE

Enquire

PEE1128045LS

Overview

Lightweight
Easy to use
Inexpensive

Product Properties

Size 280MM

Rating SDR11

Length BLANK

Degree 45

Primary Material POLYETHYLENE

UOM EACH

Joint Type Electrofusion or Butt Weld

Unprotected UV Exposed 99.9% UV stable (black only)

Mechanical Properties

Hardness Shore D 63

Thermal Properties

Thermal Conductivity 0.38w/M.k

Dimensions

Size 280MM

Weight 11.3

Standards & Accreditations

Product Standard AS/NZS 4129 "Fittings for polyethylene (PE) pipes for pressure applications"

Product Approvals and Appraisals ISO TYPE 5 - AMI 20303
WATERMARK WM20303
ISO TS29001
ISO9001 FM 597347.1
WSAA 1127 Part 1&2

Environmental Accreditation https://www.iplex.com.au/assets/Uploads/d4f35ea49e/IPL10507-Polyethylene-Pipe-EPD-V1-v4-3.pdf

POP Documents https://www.iplex.com.au/assets/Uploads/PIPA-POP001-Electrofusion-Jointing-of-PE-Pipes-and-Fittings-for-Pressure-Applications-Issue-8.0.pdf

Learn more about our
Electrofusion and Butt-Welded Fittings products

LEARN MORE ENQUIRE
