80 AVK PN16 Stainless Steel Repair Clamp (88-95) 200L 1 Part
Enquire Download Product Sheet
C3701.08820
Overview
- High strength and impact resistance
- Stainless steel nuts made out of A4 quality
- Clamps available in different diameters up to DN900
- Clamps are passivated to ensure an optimum corrosion resistance
Additional Information
AVK Reference Code 748901008802
Product Data Sheet
View
Product Properties
Size
80MM
Rating
PN16
Length
BLANK
Primary Material
STAINLESS STEEL
UOM
EACH
Rubber Ring Material
EPDM (RRJ)
Allowable Operating Temperature - Degrees
60℃
Allowable Operating Pressure - 20 Degrees Celsius
PN16
Number of Parts
1
Mechanical Properties
Density - Specific Gravity
7.10
kg/m3
Ultimate Tensile Strength
400MPa
Hardness Shore D
250
Dimensions
Size
80MM
Standards & Accreditations
Product Standard
AS/NZS 4181-2013 "Repair and off-take clamps for water industry"
Product Approvals and Appraisals
Standards Mark Licence SMK1785
