DN600 x 5.5m PN35 Irontite Red ZN/AL Ductile Iron Pipe RRJ CA Lined
Enquire Download Product Sheet
C3012.0600
Overview
Product Data Sheet
View
Product Properties
Size
600MM
Rating
PN35
Length
5.5M
Primary Material
DUCTILE IRON
UOM
LENGTHS
Joint Type
RRJ
Rubber Ring Material
EPDM (RRJ)
Colour
RED/RED BAND
Coating Specification
Zinc/Alloy 400g/m3
Lining Specification
Cement
Allowable Operating Temperature - Degrees
50℃
Allowable Operating Pressure - 20 Degrees Celsius
PN35
Socket Deflection
2.5
Mechanical Properties
Density - Specific Gravity
7.10
kg/m3
Ultimate Tensile Strength
450MPa
Poissons Ratio
0.3
Ring Bending Modulus - 3mins
165000N/mm2
Thermal Properties
Coefficient of Thermal Expansion
12.5 x 10-6/℃
Dimensions
Size
600MM
Inner Diameter
637mm
Weight
990kg
Wall Thickness
10.2mm
Socket Depth
127mm
Standards & Accreditations
Product Standard
AS/NZS 2280 "Ductile Iron Pipes and Fittings"
Product Approvals and Appraisals
Standards Mark SMK0950
WSAA Apprasial PA 1802
WSAA Apprasial PA 1802
